Permanent Smco5 Samarium Cobalt Ring Magnets

Customized Samarium Cobalt Smco Ring Magnet Permanent Powerful

Description:

A samarium–cobalt (SmCo) magnet, a type of rare earth magnet, is a strong permanent magnet made of two basic elements samarium and cobalt.They were developed in the early 1960s based on work done by Karl Strnat and Alden Ray at Wright-Patterson Air Force Base and the University of Dayton, respectively. In particular, Strnat and Ray developed the first formulation of SmCo₅.They are generally ranked similarly in strength to neodymium magnets,^[3] but have higher temperature ratings and higher coercivity.

Extremely resistant to demagnetization

Good temperature stability.

Expensive and subject to price fluctuations (cobalt is market price sensitive)

Samarium–cobalt magnets have a strong resistance to corrosion and oxidation resistance, usually do not need to be coated can be widely used in high temperature and poor working conditions.

Series

Samarium–cobalt magnets are available in two "series", namely SmCo₅ magnets and Sm₂Co₁₇ magnets.

Customized Samarium Cobalt Smco Ring Magnet Permanent Powerful
Shape	Ring
Size	Custom sizes
Grade	SmCo5/Sm2Co17
Magnetic Direction	Axially/Diametrically
Working Temperature	SmCo5 200-250℃/Sm2Co17 300-350℃
MOQ	100pcs
Lead time	25 days

Grade List:

Magnetized Direction:

Product Show:

Packing:
As the magnets have strong attraction and we will use the spacer to apart the magnets each other in case people will be hurt when take it out. Then, they will be packed in a white box of pieces each, several boxes to a carton.

+By Air: If the goods will be shipped by air, all the magnetic should be degaussed and we will use Iron sheet to shield.
+By Sea: If the goods are will be shipped by sea, we will place a pallet on the bottom of cartons.

Shipping:

Express (TNT, DHL, FedEx, UPS, etc), Air, Ocean.
A: The weight is under 40Kgs, we recommend to send them in shielding boxes to you by Express.
B: The weight is between 40Kgs-100Kgs, it can be sent by Express or Air.
C: The weight is over 100Kgs, we recommend to send them by Ocean.

If you need it, please kindly advise me the following details:

A Grade

B Size

C Coating

D Magnetization Direction

E Quantity

Then I will provide the most competitive price for you.
